TeleTank 600L - Jacketed Pressurisable Fermenter/Uni-Tank (90 Degree)
Scale up your mid-tier production pipeline with the rugged TeleTank 600L glycol jacketed fermenter. Designed to serve as both a primary fermenter and a bright beer tank, this versatile unit delivers high-volume throughput on a standard space-saving footprint. It is built for commercial cellars requiring tight temperature control, high-pressure carbonation capabilities, and reliable yeast harvesting.
Key Performance Features
90° Cone Angle for Rapid Yeast Harvesting
The sharp 90-degree conical base naturally concentrates yeast sediment and dry-hop dropouts at the bottom of the vessel. This makes purging trub fast and clean, ensuring your finished beverages achieve optimal clarity.
Standardised IBC Footprint & Mid-Sized Profile (2025mm Height)
Built on a universal 1m x 1.2m IBC footprint with a total height of 2025mm, the 600L model strikes the perfect balance between high-volume capacity and ceiling clearance. It features integrated tine pockets for standard forklift mobility and interlocking top corners for secure vertical stacking.
Pump-Free Liquid Transfers
Operating safely at up to 2-bar (29 psi) working pressure, the TeleTank 600L lets you carbonate beverages directly in the tank. Use top gas pressure to push finished product smoothly to a packaging line or secondary tank without risking mechanical shearing or oxygen pickup from standard pumps.
Superior Thermal Efficiency
The high-density polyurethane insulation paired with a heavy-duty dimple cooling jacket minimises temperature drift. It connects flawlessly to your commercial glycol chiller via 3/4" ports, keeping cold crashes rock-solid even in hot ambient warehouse conditions.
Top-Access Manway & Accessories
Equipped with a secure Top Manway for easy interior cleaning, a 4" TC addition port for dry-hopping or optional VFD mixers, and a 2" TC port for optional heating element integration.
📊 TeleTank Range Specifications
| Model Name | Volume (L) | Height (mm) | Footprint (mm) | Cone Angle | Manway Location | Working Pressure |
| TeleTank 250L | 250L | 1434mm | 1000 x 1200 | 150° Shallow | Top Manway | 2 Bar (29 psi) |
| TeleTank 300L | 300L | 1560mm | 1000 x 1200 | 90° Steep | Top Manway | 2 Bar (29 psi) |
| TeleTank 500L | 500L | 1634mm | 1000 x 1200 | 150° Shallow | Top Manway | 2 Bar (29 psi) |
| TeleTank 600L | 600L | 2025mm | 1000 x 1200 | 90° Steep | Top Manway | 2 Bar (29 psi) |
| TeleTank 1000L | 1000L | 2384mm | 1000 x 1200 | 150° Shallow | Side Manway | 2 Bar (29 psi) |
| TeleTank 1200L | 1200L | 2970mm | 1000 x 1200 | 90° Steep | Side Manway | 2 Bar (29 psi) |
Common Technical Specs across all models:
- 304 Grade Stainless Steel construction
- Sanitary welding throughout
- 3/4" Glycol Inlets/Outlets
- 4-inch TC Hop/Addition Port
- AS1210:2010 Pressure Vessel Design Registration.
